Type T Thermocouple Probe 1/16" Diameter 6 Inches Long Stainless Steel Sheath Grounded Junction with Miniature Connector

Evosensors

$65.00
SKU: T1X-S304-062-GX-6-MPCX

   Call 407 420-8080 or Email info@evosensors.com for Technical and Sales Support

Type T Thermocouple Probe 1/16" Diameter 6 Inches Long Stainless Steel Sheath Grounded Junction with Miniature Connector

  • Type T Thermocouple Probe has a 1/16" Diameter 6 Inch Long Stainless Steel Sheath with a Miniature Connector for quick connection capabilities.
  • Temperature Operating range is -454 to 662°F (-270 to 350°C)
    • Standard accuracy is  +/- 1.0C or +/- .75% whichever is greater.
    • Reduced accuracy will occur with temperatures below negative -380°F (-200°C)
  • Grounded Thermocouple junction provides a Fast Response while protecting the thermocouple wires.
  • 1/16" (.062" or 1.59mm) Diameter is a Bendable MI Cable design provides excellent flexibility and good strength.
  • Instrument Connection is a miniature male flat pin thermocouple connector with a -40 to 400°F (-40 to 200 °C) rated thermoplastic body.
    • The connector can accurated transfer the full range of Type T thermocouples.
  • Applications and Industries - include the processing, packaging and transportation of Food, Pharmaceutical, Packaging, Biomedical and other areas such as Labs, Cryogenics where the excellent accuracy/ repeatability of Type T thermocouple between –380 to 392°F (–200C to 200°C) is utilized.
  • EvoSensors Part Number: T1X-S304-062-GX-6-MPCX
  • Location: B-5-11
  • Click here for additional Information on Type T Thermocouples
