Type T Thermocouple 1/8" Diameter Probe 3 Inches Long with Transition to 60 Inches (5 ft) Wire Leads and Miniature Male Connector

Evosensors

$50.00
SKU: T1X-S304-125-UX-3-FPXX-60-MPCX

   Call 856 579-7490 or Email info@evosensors.com for Technical and Sales Support

Type T Thermocouple Probe - 3 inches long 1/8" Diameter Stainless Steel Sheath Ungrounded with a Transition to 60 Inches (1.5 meters) of FEP Lead Wire and Miniature Connector

  • Temperature Operating range of the probe is -380 to 600°F (-200 to 315°C)
  • Ungrounded Thermocouple design minimizes electrical interference and provides protection to the thermocouple junction.
  • Probe Transition to a Stainless Steel metal fitting backfilled with high temperature epoxy and Stainless Steel spring with 60 Inches (1.5 Meters) of FEP 400°F (200°C) rated lead wire.
  • Instrument Connection -  Miniature Male Plastic Connector flat pin design rated to 400°F (200°C) and silicone rubber strain relief
  • Industries and Applications include Biotechnology, Cold Storage, Battery Technology development, Medical, along with overall Research and Development
  • Click for PDF Spec Sheet
  • EvoSensors Part Number: T1X-S304-125-UX-3-FPXX-60-MPCX
