Surface Thermocouple Type T Fast Response with Surface Mount Adhesive Patch and 120 inches of Fiberglass Insulated Wire with Stripped Leads

Evosensors

$27.00
SKU: T2S-TAPE-REC-FW-1-FGXX-120-STWL

   Call 407 420-8080 or Email info@evosensors.com for Technical and Sales Support
Type T Thermocouple Sensor for Surface Temperature Measurement with Super-Fast Response and Easy Mounting
  • The Fast Response Type T Thermocouple has a 1" long x .500" Wide x .012" Thick Polyimide Tape Fiberglass Reinforced Patch with Silicone Adhesive and Lead Wires.
  • The Response Time can be as fast as .015 Seconds. The temperature operating range is -90 to 500 F (-70 to 260 Cwith capabilities to 600 F (315 C) with thermal epoxy cement.
  • The sensor is made with SLE Accuracy thermocouple wire with a Flattened Bead design encased in Self Adhesive Polyimide Tape providing easy and fast surface mounting.
  • The tape section of the sensor transitions to 120 inches of Fiberglass insulated wire and stripped leads. The wire is rated to 900 F (482 C), it is a 30 Gage Solid construction with Fiberglass insulated wires and outside jacket. The overall outside diameter is a nominal .037" x .050".
  • The design and overall performance capabilities of this product provides accurate and fast surface temperature for Semi-Conductor, Oil and Gas, Off-Road and Agriculture Equipment, Automotive, Aerospace, overall Product Development and Testing along with many other industries.
  • EvoSensors Part Number T2S-TAPE-REC-FW-1-FGXX-120-STWL
  • Location: C-1-12

Consider the following Accessories to complete your Sensor System

Miniature Thermocouple Connector Accessories Type T Thermocouple Connectors Standard Size Female Type T Thermocouple Wire Type T 24 Gage PFA Insulated 100 ft Long
